Fast Shift Sensor
Fast Shift Sensor (FSS), quickshifter for various BMW Superbike models
€569.00
Product number:
7725B004A00
The Fast Shift Sensor is a compact, performance-optimized quickshifter, suitable for many BMW Motorrad Superbike models. The current version has an improved bearing and sealing of the sensor as well as a robust and precise design for use under high mechanical and thermal loads under racing conditions.
Technical features:
- Revised sensor version with optimized bearing and seal
- Shortened shift travel and reduced shift time for faster gear changes
- Shift direction possible in pull and push direction
- CNC-milled aluminium housing, black anodized
- Very low overall height
- Incl. shift rod, length: 155 mm
- Thread: M6 external / M6 internal
- (Re)programmable Hall sensor
- Spring-loaded measuring element, travel: ±3 mm, force range: max. ±25 kg
- Compatible with standard and motorsport electronics (M RCK)
The Fast Shift Sensor fulfills high requirements for precision, durability and integration capability in the toughest racing situations.
Weight: 0.175 kg
Technical features:
- Revised sensor version with optimized bearing and seal
- Shortened shift travel and reduced shift time for faster gear changes
- Shift direction possible in pull and push direction
- CNC-milled aluminium housing, black anodized
- Very low overall height
- Incl. shift rod, length: 155 mm
- Thread: M6 external / M6 internal
- (Re)programmable Hall sensor
- Spring-loaded measuring element, travel: ±3 mm, force range: max. ±25 kg
- Compatible with standard and motorsport electronics (M RCK)
The Fast Shift Sensor fulfills high requirements for precision, durability and integration capability in the toughest racing situations.
Weight: 0.175 kg
Delivery Scope
1x Fast Shift Sensor FSS
1x Shift rod, 155 mm
2x Ball joint head
Note
When using the OEM rearset system, a shorter shift rod (135 mm) must be used (see Accessories).
| Manufacturer | Model | Type | Model Year | Variant | Capacity |
|---|---|---|---|---|---|
| BMW | M 1000 R | KM3 | 2023 - 2024 | 0E81 | 999 |
| BMW | M 1000 RR | K66 | 2021 - 2022 | 0E71 | 999 |
| BMW | M 1000 RR | K66 | 2023 - 2024 | 0P01 | 999 |
| BMW | M 1000 RR | K66 | 2025 - | 0P41 | 999 |
| BMW | M 1000 XR | KM9 | 2024 - | 0E91 | 999 |
| BMW | S 1000 R | K63 | 2021 - 2024 | 0E51 | 999 |
| BMW | S 1000 RR | K67 | 2019 - 2022 | 0E21 | 999 |
| BMW | S 1000 RR | K67 | 2023 - 2024 | 0E61 | 999 |
| BMW | S 1000 RR | K67 | 2025 - | 0P21 | 999 |
Shift rod for fast shift sensor, needed if OEM rearset is used
4671A135A00
